12G-SDI Input Card for Flex Matrix Pro

4-Port 12G/6G/3G/HD-SDI Input at 11.88Gbps — Dante/AES67 & TAA

FLEX-PROSDI-IN
Tier pricing and stock
Price, inventory and ordering are open to approved dealers. Specifications, drawings and documents stay open to everyone.
Apply Sign in
Overview

Add four 12G-SDI (BNC) inputs to any Flex Matrix Pro chassis. The FLEX-PROSDI-IN delivers 4K60 4:4:4 at 11.88Gbps with SMPTE/ITU compliance, scaling, and Dante/AES67 per port.

Seamless switching. EDID/HDCP management. Hot-swappable. TAA compliant. 12G/6G/3G/HD-SDI auto-adaptation.

Key features
  • 4× 12G-SDI (BNC) inputs — hot-swappable across all Flex Pro chassis (16×16 to 128×128)
  • 4K60 4:4:4 at 11.88Gbps • HDCP 2.2 • HDR
  • Dante/AES67 network audio • 8ch LPCM High-Res Audio
  • Independent scaling per input • seamless switching • EDID/HDCP management
  • 12G/6G/3G/HD-SDI • up to 11.88Gbps • SMPTE/ITU auto-adaptation • auto reclocking
  • Hot-swappable • TAA compliant
ManualInstallation & operation
Spec sheetFull specification

UPC 813982023864
