8×8 HDBaseT Matrix Switcher with 4K60 & CAT Extension (70m)

Name: 8×8 HDBaseT Matrix Switcher with 4K60 & CAT Extension (70m)
Brand: KanexPro
SKU: MMX-8X8CAT-70M

18Gbps 8-Source HDMI Matrix with Mirrored CAT Outputs, PoC Receivers & Web GUI

MMX-8X8CAT-70MUPC 813982023659

In stock

8×8 HDBaseT Matrix Switcher with 4K60 & CAT Extension (70m) – KanexPro MMX-8X8CAT-70M

8×8 HDBaseT Matrix Switcher with 4K60 & CAT Extension (70m) – KanexPro MMX-8X8CAT-70M, view 2

Trade pricing and stock

Specifications, drawings and documents stay open to everyone. Net pricing, stock by warehouse and ordering need an approved trade account.

Apply Sign in

Approval is usually same working day.

Overview

The KanexPro MMX-8X8CAT-70M is an 18Gbps 8×8 HDMI matrix switcher with simultaneous mirrored HDBaseT CAT outputs, designed for professional AV installations that require flexible, long-distance signal distribution from a single rack location. It connects eight HDMI 2.0b sources to up to sixteen displays at once — eight via direct HDMI and eight via CAT6 extension to the included PoC-powered HDBaseT receivers, reaching up to 230ft (70m) per run. A single CAT6 cable carries the full 4K60 4:4:4 signal and simultaneously powers the remote receiver via 12V Power over Cable, eliminating the need for a separate power supply at each remote display location.

Every output supports resolutions up to 4K2K@60Hz (YUV 4:4:4) with 18Gbps uncompressed bandwidth, full HDR format pass-through (HDR10, HDR10+, Dolby Vision, HLG), and HD audio including LPCM 7.1, Dolby TrueHD, Dolby Digital Plus, DTS-HD Master Audio, and DTS-X. An independent 4K-to-1080p downscaler on each output allows mixed-resolution display environments without additional hardware. Advanced EDID management, CEC display control, and one-way IR matrix routing complete the signal chain. The matrix is controlled via front panel buttons, IR remote, RS-232 serial, TCP/IP LAN, or a browser-based Web GUI — compatible with Crestron, AMX, and other third-party control systems.

Ideal for conference rooms, classrooms, control rooms, digital signage networks, and multi-zone AV distribution where sources must reach displays across a floor or building without running multiple HDMI cables.

Package Contents: 1× MMX-8X8CAT-70M Matrix • 8× CAT Receivers • 1× IR Remote • 1× 12V/5A Power Supply • 1× RS-232 Serial Cable (1.5m, DP9 female to 3-pin Phoenix) • 8× IR Blaster Cables (1.5m) • 9× IR Receiver Cables (1.5m) • 8× Machine Screws (KM3×6) • 18× Mounting Ears (Matrix + Receivers) • 1× User Manual

Key features

8 HDMI inputs • 8 HDMI + 8 mirrored CAT outputs • 8 PoC CAT receivers included
18Gbps video bandwidth • HDMI 2.0b • HDCP 2.2/1.x • DVI 1.0 compatible
Up to 4K2K@60Hz (YUV 4:4:4) on all HDMI and CAT ports
HDR10, HDR10+, Dolby Vision, HLG pass-through
CAT extension up to 230ft / 70m via single CAT6 cable with 12V PoC
Independent 4K→1080p downscaler per output for mixed-resolution displays
LPCM 2.0/5.1/7.1, Dolby Digital, Dolby TrueHD, DD+, DTS-ES, DTS-HD Master, DTS-X audio pass-through
One-way IR matrix routing • CEC display control • Advanced EDID management
Control via front panel buttons, IR remote, RS-232, TCP/IP (LAN), and Web GUI
1U rack-mountable metal enclosure • 12V PoC on all CAT ports

Technical
HDMI Compliance	HDMI 2.0b
HDCP Compliance	HDCP 2.2 / 1.x
Video Bandwidth	18 Gbps
Video Resolution	Up to 4K2K@50/60Hz (YUV 4:4:4)
Color Space	RGB 4:4:4, YCbCr 4:4:4 / 4:2:2 / 4:2:0
Color Depth	8/10/12-bit (1080p@60Hz) • 8-bit (4K2K@60Hz 4:4:4) • 8/10/12-bit (4K2K@60Hz 4:2:2/4:2:0)
HDR Formats	HDR10, HDR10+, Dolby Vision, HLG
HDMI Audio	LPCM 2.0/2.1/5.1/6.1/7.1, Dolby Digital, Dolby TrueHD, DD+, DTS-ES, DTS-HD Master, DTS-HD HRA, DTS-X
ESD Protection	Human-body Model: ±8kV (air-gap) / ±4kV (contact)
Connection
HDMI Input	8× HDMI Type A [19-pin female]
HDMI Output	8× HDMI Type A [19-pin female]
CAT Output	8× RJ45 [HDBaseT, 12V PoC]
Matrix Control	1× TCP/IP [RJ45] • 1× RS-232 [3-pin Phoenix] • 8× IR OUT • 1× IR EXT [3.5mm]
CAT Receiver	IN: 1× RJ45 • OUT: 1× HDMI Type A • 1× IR IN / IR OUT [3.5mm] • 1× SERVICE [Micro USB]
CAT Extension
Transmission Distance	230ft / 70m (via single CAT6 cable)
PoC	12V Power over CAT cable to receivers
Mechanical
Housing	Metal Enclosure, Black
Matrix Dimensions	440mm (W) × 250mm (D) × 44.5mm (H) — 1U
Receiver Dimensions	61mm (W) × 88mm (D) × 18mm (H)
Weight	Matrix: 3.2 kg • Receiver: 155g each
Power Supply	Input: AC 100–240V 50/60Hz • Output: DC 12V/5A (CE/FCC/UL)
Power Consumption	50W max
Operating Temp	32–104°F / 0–40°C
Storage Temp	−4–140°F / −20–60°C
Humidity	20–90% RH (non-condensing)
Cable Length (HDMI IN/OUT)
4K60	Up to 16ft / 5m
4K30	Up to 32ft / 10m
1080p60	Up to 50ft / 15m

8×8 HDBaseT Matrix Switcher with 4K60 & CAT Extension (70m) panel drawing

8×8 HDBaseT Matrix Switcher with 4K60 & CAT Extension (70m) system diagram

8×8 HDBaseT Matrix Switcher with 4K60 & CAT Extension (70m) applications

Manual~~Installation and operation~~

Spec sheet~~Full specification~~

Sales sheet~~For bid packages~~

What is the maximum transmission distance for 4K60 video?

4K60 4:4:4 is supported up to 230ft / 70m via a single CAT6 cable to the included HDBaseT receiver. For longer distances, consider the MMX-8X8CAT-150M which extends to 492ft / 150m.

Can I route any input to any output independently?

Yes. The matrix supports fully independent routing — any of the 8 HDMI inputs can be assigned to any or all of the 8 HDMI/CAT output pairs simultaneously, including the same source to multiple outputs.

What cable type is required for CAT outputs?

Use CAT6 or CAT6A shielded cable (STP). Standard CAT5e may work at shorter distances but is not recommended for full 70m performance. Do not use crossover cables — direct interconnect (T568B) wiring only.

Do I need separate power supplies for the CAT receivers?

No. The MMX-8X8CAT-70M provides 12V Power over CAT (PoC) on all 8 CAT outputs. The included receivers are powered directly through the CAT6 cable — no additional power adapter is required at the remote end.

How do I access the Web GUI?

Connect the TCP/IP RJ45 port to your network. The default IP address is 192.168.1.100. Open a browser and navigate to that address. The default login is Admin / admin. Change the password after initial setup.

My display shows no video on a CAT-connected receiver. What should I check?

Verify CAT6 cable wiring (T568B, no crossover), check that the PoC LED on the receiver is illuminated, confirm the cable does not exceed 70m, and re-seat the RJ45 connectors. Also verify the EDID setting matches the display resolution using the Web GUI.

What is included in the box?

1x MMX-8X8CAT-70M matrix, 8x CAT receivers, 1x IR remote, 1x 12V/5A power supply, 1x RS-232 cable (1.5m), 8x IR blaster cables, 9x IR receiver cables, mounting ears, and user manual.

Does the matrix support audio de-embedding?

The MMX-8X8CAT-70M does not include coaxial or analog audio de-embedding outputs. For audio de-embedding, see the MMX-8X8CAT-150M which includes coaxial and balanced analog audio outputs per HDBaseT port.

Can I mix 4K and 1080p displays on the same matrix?

Yes. Each output has an independent 4K→1080p downscaler that can be enabled per output, allowing mixed-resolution displays to be connected simultaneously without affecting other outputs.
