Name: Long-Range 4K HDMI over HDBaseT Extender Kit — 150M / 492ft
Brand: KanexPro
SKU: EXT-4KHD150M2

Overview

Extends 4K HDMI, RS-232, and bi-directional IR up to 150 meters over a single Cat5e/6 cable — eliminating the signal degradation and distance limitations that plague standard HDMI runs. The EXT-4KHD150M2 delivers uncompressed 4K2K@60Hz 4:4:4 at distances up to 120 meters and 1080p at up to 150 meters, with full HDCP 2.2 compliance and support for HDR, HDR10+, Dolby Vision, and HLG.

Designed for commercial AV installations where sources and displays are separated by long cable runs, the extender includes an HDMI loop output on the transmitter for local monitoring, de-embedded analog stereo audio on the receiver, and Power over Cable (PoC) so only one end requires a power adapter. The compact metal enclosure with mounting ears fits standard AV rack environments.

Key features

HDCP 2.2 / HDCP 1.4 and DVI 1.0 compliant
Supports 18Gbps video bandwidth
Maximum extended transmission distance via single Cat5e/6 cable: 394ft / 120 meters for 4K2K signal; 492ft / 150 meters for 1080P signal
Supports one HDMI loop output on the transmitter
De-embedded audio to analog stereo output on receiver
Bi-directional IR, RS-232, and CEC pass-through
HDR, HDR10+, Dolby Vision, and HLG supported
Supports PoC (Power over Cable) function
Compact design for easy and flexible installation

Technical
HDCP Compliance	HDCP 2.2 / HDCP 1.4
Video Bandwidth	18Gbps
Video Resolution	4K2K 50/60Hz 4:4:4, 4K2K 50/60Hz 4:2:2, 4K2K 50/60Hz 4:2:0, 4K2K 30Hz 4:4:4, 1080p, 1080i, 720p, 720i, 480p, 480i, All HDMI 3D TV formats, All PC resolutions including 1920x1200
Color Space	RGB / YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0
Color Depth	8/10/12-bit (1080P60Hz, 4K30Hz, 4K60Hz YCbCr 4:2:2/4:2:0); 8-bit (4K60Hz 4:4:4)
HDR Formats	HDR, HDR10+, Dolby Vision, HLG
HDMI Audio Formats	LPCM 2.0/2.1/5.1/6.1/7.1, Dolby Digital, Dolby TrueHD, Dolby Digital Plus (DD+), DTS-ES, DTS HD Master, DTS HD-HRA, DTS-X
L/R Audio Formats	PCM 2.0
ESD Protection	Human body model — ±8kV (Air-gap discharge) & ±4kV (Contact discharge)
Connection — Transmitter
TX Inputs	1× HDMI Type A [19-pin female]
TX Outputs	1× HDMI Type A [19-pin female] (Loop), 1× HDBT OUT [RJ45, 8-pin female]
TX Control	1× IR IN [3.5mm Stereo Mini-jack], 1× IR OUT [3.5mm Stereo Mini-jack], 1× RS-232 [Phoenix jack], 1× SERVICE [Mini-USB, Update port]
Connection — Receiver
RX Inputs	1× HDBT IN [RJ45, 8-pin female]
RX Outputs	1× HDMI Type A [19-pin female], 1× AUDIO OUT [3.5mm Stereo Mini-jack]
RX Control	1× IR IN [3.5mm Stereo Mini-jack], 1× IR OUT [3.5mm Stereo Mini-jack], 1× RS-232 [Phoenix jack], 1× SERVICE [Mini-USB, Update port]
Mechanical
Housing	Metal Enclosure
Color	Black
Dimensions	Transmitter / Receiver: 140mm (W) × 65mm (D) × 18mm (H)
Weight	Transmitter: 160g, Receiver: 155g
Power Supply	Input: AC 100-240V 50/60Hz, Output: DC 24V/1A (Locking connector)
Power Consumption	9.36W
PoC	Supported (TX or RX powered)
Operating Temperature	32-104°F / 0-40°C
Storage Temperature	-4-140°F / -20-60°C
Relative Humidity	20-90% RH (no condensation)
Extension Range (Cat5e/6)
4K2K	394ft / 120M
1080P	492ft / 150M
Cable Length (HDMI)
4K60	Up to 16ft / 5M
4K30	Up to 32ft / 10M
1080P60	Up to 50ft / 15M
Package Contents
1× 18Gbps HDMI over HDBaseT Extender (Transmitter), 1× 18Gbps HDMI over HDBaseT Extender (Receiver), 1× IR Blaster cable (1.5 meters), 1× 20-60KHz IR Receiver cable (1.5 meters), 4× Mounting Ear, 2× 3-pin Phoenix connector, 1× 24V/1A Locking Power adapter, 1× User Manual
